Broomwade compressor service manual

Compair Broomwade CD50. Manufacturer: CompAir COMPAIR BROMWADE Refrigerant Dryer, Type CD50, Serial No CO20/0104, MFD 1984, Maximum Presure 14 Bar, Motor 0.73kw, Electrics 240v, 1ph, 50 Cycles. Shop by Broomwade Model Numbers. Model Series: V We carry hundreds of replacement Broomwade air compressor parts from the hard-to-find, to the most common, including air filters, air/oil separators, and oil filters as well as complete rebuild kits and individual parts.

Broomwade 6000e manualManualBroomwade 6000 manualBroomwade

CompAir BroomWade Cyclon 330: Transcript

Broomwade Ac41 Compressor Manual

  • CompAir BroomWade Limited page 46 ..

  • page 17 Cyclon Series User Manual – General Description 6.3 Modulating Control (Optional) In the ‘Modulating’ mode the opening and closing of the suction regulator inlet valve is controlled by the negative regulator. As the demand for compressed air rises and falls, the valve modulates between fully open and fully closed. When the compressor is starte ..

    Page: 17

  • CompAir BroomWade Limited page 4 WARRANTY The conditions of the CompAir BroomWade Warranty are set out in the company’s standard Conditions of Sale available from the Distributor supplying the machine. MAINTENANCE To ensure the continued trouble-free operation of the compressor unit it is important that periodic maintenance and servicing are carried out in ..

  • Ableton live 10 keygen online. page 11 Cyclon Series User Manual GENERAL DESCRIPTION Page Compressor 12 Air-End 12 Electronic Controller 12 Protection and Safety Equipment 12 Relief Valve 12 Blowdown System 12 Minimum Pressure Non-return Valve 12 Air/Oil System 14 Description 14 Operation 14 Regulation System 16 Description 16 On/Off Control 16 Modulating Control (Optional) 17 2 ..

    Page: 11

  • CompAir BroomWade Limited page 54 3.4.3 To Change the Oil Filter: The compressor must be stopped. 1. Open the door to the service area. 2. Unscrew the old oil filter from the manifold block and discard. 3. Apply a light film of oil to the seal of the new element and prime the new filter with oil. 4. To fit the new element, screw it into the manifold block u ..

  • CompAir BroomWade Limited page 56 3.5.1 Adjustment After Fitting New Drive Belt(s): 1. Release the 1 /4 turn fasteners and remove the LH side panel. 2. Loosen the lock nut (1) and turn the nut (2) clockwise until the adjuster (3) contacts the cut-out in the spring retainer (4). 3. Screw the nut (2) back one turn and tighten the lock nut (1). 4. Check that t ..

    Page: 56

  • CompAir BroomWade Limited page 40 2. PROGRAM MODE 2.1 Program Mode Routine ‘Program mode’ is used to access, view and/or alter the operating parameters and options stored in the memory of the controller. 1. To enter the ‘Program mode’ press STOP (B3) then press and hold PLUS (B4) and MINUS (B5) together. 2. After five seconds indicators L1 to L8 ..

  • CompAir BroomWade Limited page 50 2.1 Separator Filter Part Number Table Model Qty. Max Rated Separator Cyclon Pressure Filter (Bar) 330/337 1 7·5 to 13 98262-223 345 2 7·5 to 13 98262-223 2.3 Drive Belt Part Number Table (50 Hz) Model Qty. Maximum Rated Pressure 7.5 bar 8.2 bar 10 bar 13 bar 330 4 98080-152 98080-152 98080-152 98080-153 337 4 98080-153 98 ..

    Page: 50

  • page 25 Cyclon Series User Manual 5 COMMISSIONING Page Commissioning Procedure 26 Preliminary Checks 26 Pressure Calibration 27 Checking/Altering Program Mode Values 28 Final Checks 30 Negative Regulator (Modulating Control Only) 33 Commissioning Checklist 34 ..

  • page 27 Cyclon Series User Manual – CommissioningCyclon Series User Manual – Commissioning 1.2 Pressure Calibration Note: The values shown throughout these procedures are examples only. Ensure set values are compatible with the compressor model. No. Action Reason Display 1. Switch power ‘ON’ at the isolator 0.0 Bar and allow the controller to initial ..

    Page: 27

  • page 51 Cyclon Series User Manual – Maintenance 1. Intake Air Filter 2. Suction Regulator 3. Oil Cooler 4. Drive Belt 5. Motor Bearings 6. Minimum Pressure/Non-return Valve 7. Separator Element 8. Oil Filter Element 9. Oil Drain Valve 10. Control Air Isolating Valve 11. Oil Filler Cap 12. Oil Level Sightglass 13. Air Cooler 14. Display Panel 15. Belt Tensi ..

  • page 7 Cyclon Series User Manual – Safety Procedures 3. GENERAL SAFETY PRECAUTIONS If using compressed air for cleaning purposes, ensure safety regulations are complied with and appropriate clothing and eye protection is worn. Never direct compressed air onto your skin or at other people. Never use compressed air to clean loose dirt from clothing. Before ..

    Page: 7

  • CompAir BroomWade Limited page 62 Q101 MCB R201 Temperature Sensor S101 Emergency Stop Button S201 Air Filter T101 Control Transformer Y101 Load Solenoid Y102 Drain Solenoid Option ELECTRICAL CONNECTIONS DIAGRAM F1 Fused Terminal 1·6A F2 Fused Terminal 3·15A F101 Motor Overload Relay KM101 Main Contactor KM102 Star Contactor KM103 Delta Contactor M101 Dri ..

  • CompAir BroomWade Limited page 12 GENERAL DESCRIPTION 1. COMPRESSOR The unit is a fully enclosed, air cooled, single- stage, rotary screw compressor. The compressor air-end is belt driven by an electric squirrel-cage induction motor. The drive belts are mounted on pulleys fitted to the shafts of the drive motor and air-end. The compressor unit consists of th ..

    Page: 12

  • CompAir BroomWade Limited page 6 2. WARNINGS, CAUTIONS AND NOTES 2.1 Warnings Warnings call attention to operations or procedures involving specific hazards which could cause injury or death and are identified by the following symbols on the unit and in the text of the manual. WARNING: RISK OF DANGER WARNING: RISK OF ELECTRIC SHOCK WARNING: RISK OF HOT SURF ..

  • page 45 Cyclon Series User Manual – Operation 4.4 Remote Group Fault Output 4.4.1 Group Fault Relay The control card is fitted with a group fault relay, the relay contacts being available for switching remote facilities. The relay contacts are rated for a maximum of 250V ac at 5A and are connected to controller terminal X08, pins 9 and 10. 4.4.2 Group Faul ..

    Page: 45

  • page 19 Cyclon Series User Manual LEADING PARTICULARS 3 .. Audi a6 mmi 2g software update.

  • Trials in tainted space virility. page 61 Cyclon Series User Manual APPENDIX 1 Electrical Connections ..
